The Talaria Sting is powered by an impressive 60V 38Ah lithium-ion battery which can be swapped and/or removed in seconds, allowing the possibility of a limitless range with a simple battery swap. Using electric automobile grade LG 21700 cells combined with state-of-the-art programmed BMS, our torque and efficiency make this bike an outstanding performer on the road or off.

TAKE IT TO THE STREETS

The Talaria Sting is powered by an impressive 60V 38Ah lithium-ion battery which can be swapped and/or removed in seconds, allowing the possibility of a limitless range with a simple battery swap.

Using electric automobile grade LG 21700 cells combined with state-of-the-art programmed BMS, our torque and efficiency make this bike an outstanding performer on the road or off.

TAKE IT WHEREVER, WHENEVER

Forged for adventure and built for life, Talaria Sting is a lightweight and compact bike frame. Using 6061 aluminium alloy with a superior forging process of 6000 tons of pressure, the frame is qualified to assure you a safe, fun and most importantly comfortable riding experience through even the toughest terrains.

BUILT FOR ULTIMATE PERFORMANCE

Using high-quality hardware, superb layout and smart programming, the controller enables to have an extraordinary ability for transient current impact resistance, ultra-strong anti-interference, high-precision EABS voltage, discharge current control, error inspection and correction. This guarantees to bring the rider a powerful, exciting and safe riding experience.

NIGHTRIDER

The dash features a high-contrast OLED display, which will offer riders a clear data display with low power consumption. The display menu provides a range of information, which include top/average speed, range, battery data, riding mode, error codes, regen level and more.

The dash is also adjustable to allow different settings for different wheel sizes, sprocket sizes, motor regen levels, and changes between KM/H and MPH to enhance the compatibility of the bike.

SPECIFICATIONS

Licence Required

CBT LICENCE

Top Speed

30 MPH (Restricted)

Range*

50 MILES

Battery

60V 38.4Ah Lithium LG Cells

Suspension Front

Telescopic Forks

Suspension Rear

Monoshock

Display

TFT

Max Power

3700W @ 2100rpm

Braking Type

Standard

Brakes

F: Hydraulic Disc, R: Hydraulic Disc

Primary Drive

Chain

Tyres

F: 70/100-19, R: 80/100-19
* RANGE IS DEPENDANT ON VARYING RIDING CONDITIONS AND HABITS SUCH AS SPEED/WEIGHT/BREAKING

Motor

Rated Voltage- 60v (DC)

Rated Power / Peak Power- 3700W @ 2100rpm

Shaft Output Torque- 29.5nm

Transmission- Gearbox + Chain

Rated Torque / Peak Torque- 8.5nm / 31.8nm

Peak Efficiency- 96.6%

Type- PMSM

Mounting Position- Centre Frame

Weight- 7kg

External Diameter- 180mm

Axial Length- 130mm

Cooling Method- Air Cooled

Controller

Type- FOC

Weight- 1.6kg

Dimensions (LxWxH)- 240mm x 110mm x 50mm

Peak Efficiency- 98.5%

Travelling Wave Current- 85A

Highest Temperature- 100 °C

Powertrain

Rated Rotation Speed- 4300 rpm

Range of Rotation Speed- 0-5300 rpm

Peak Efficiency- 98%

Range of Efficiency- 1.4mm – 22.5mm

Battery

Max Range *- 63 Miles

Battery- 60v 38.4A Lithium LG Cells

Speedometer- TFT Digital

Battery Life Time- 800 Cycles Before

Charger- 10A 60V

Charging Time **- 4 Hours

* Range is dependant on speed/weight/braking and other factors

** Charging time is from 0-100%

Chassis

Max Load- 100kg

Net Weight- 58kg

Forks- Manitou (Optional) / RST – DNM

Wheel Type- Spoke Wheels 19×1.6

Brakes- 4 Piston Caliper Hydraulic Brakes

Dimensions (LxWxH)- 1870mm x 780mm x 1040mm

Chassis – Swing Arm Material- 6061 T4 & T6 Aluminium Alloy

Chassis Construction Method- Forged 8000 Tons of Pressure

Rear Shock Absorber- Fastace with Linkage

Front Tyre Size- 70/100-19

Rear Tyre Size- 80/100-19

Chassis Weight- 9.5kg

Chassis Surface- Anodizing Paint Treated

Headlight- LED

Tyres- CST

Brake Discs- 203mm

Minimum Ground Clearance- 270mm
