Here is the Bomma TTO. “The Take over” is the new benchmark 27.5” single speed street-bike for those who demand an all-round performer for combos and traffic work but find the 29” bikes just a little too big. .. With an emphasis on “buy it and ride-it” (no upgrades needed), We took our tried and tested geometry/know-how and packaged it into a lighter stiffer machine. We then wrapped that up in a selection of exciting new colourways to form the basis of your next individual creation. TTO starts life as a lightweight single speed bike, but has been cleverly designed for you to easily switch to gears down-the-line. Simply change-out the rear wheel, rear dropout insert, adding a mech and shifter and you now have a geared bike like BOMMA THRUST. All cable routing is pre-installed and we offer the mech insert as an additional part.
Featuring Shimano Hydro (MT200), hollow tech sealed BB, hydro-formed 6061 alloy frame with CNC machined components and peg mounts as standard, SnakeskinS (Sticky) tyres and 29” alloy double wall rims. To name but a few of the impressive features.
Geometry | |
---|---|
(A) Top tube length | 589.5mm |
(B) Head tube length | 105mm |
(C) Standover | 725mm |
(D) Reach | 432mm |
(E) Stack height | 554mm |
(F) Bottom Bracket | 11.6 |
Geometry diagram |
Geometry
|
Specs | |
Frame | TTO 27.5 |
Forks | Bomma Flanged 27.5 |
Handlebars | Bomma 2 piece W762mm x H168mm |
Grips | Lucky 6 Grips |
Headset | 1 1/8” Integrated – Sealed bearings |
Stem | Mafiabikes forged Topload – 50mm Reach |
Pedals | 9/16” Mafiabikes plastic PP |
Saddle | Mafiabikes Wheelie seat – Railed |
SEATPOST | Ø31.6mm micro adjust alloy |
Seat Clamp | Ø35mm External QR |
Cranks | 170mm forged direct mount alloy cranks – 24mm hollow spindle |
Chainring/sprocket front | 32t Direct Mount Steel thick-thin |
Sprocket/cassette rear | 15t Freewheel |
Tyre Front | Lagos Snakeskin “S” Super Soft Compound 27.5″ x 2.5″ |
Tyre Rear | Lagos Snakeskin “S” Super Soft Compound 27.5″ x 2.5″ |
Front hub | Alloy shell, 3/8″ axle, sealed bearings |
Rear hub | Alloy shell, 3/8″ axle, BMX threaded Freewheel, Fully sealed bearings, Disc |
Rim front | 27.5″ 35mm Wide double wall alloy 36h |
Rim rear | 27.5″ 35mm Wide double wall alloy 36h |
Brake Front | Side pull cable brake (supplied in roadkit) |
Brake Rear | Shimano MT200 – hydraulic disc brake 160mm rotor |
Tech | |
BB type | 73mm ISO External (24mm) |
Headset type | 1 1/8” integrated |
Rear axle/hub spacing | 3/8″ x 135mm axle |
Max tyre width rear | 66mm / 2.6″ |
Seatpost/seatclamp | Ø31.6mm post, 35mm seatclamp |
Front axle/hub spacing | 3/8″ x 100mm axle |
Max tyre width front | 66mm / 2.6″ |
Frame construction and details | 6061 T6 Aluminum, IS rear brake tab, heavy duty hydroformed downtube and chainstays, peg mount integrated dropouts, interchangable geared to single speed dropout inserts |
Road kit | Included |
