| Geometry | |
|---|---|
| (A) Top tube length | 561mm |
| (B) Chainstay length | 385mm |
| (C) Head angle | 69° |
| (E) Seat tube angle | 70.5° |
| (F) Standover | 710mm |
| (G) Reach | 400mm |
| (H) Stack height | 563mm |
| (J) Fork offset | 41mm |
| Specs | |
| Frame | Blackjack Pro |
| Forks | Manitu Circus Comp 100mm |
| Handlebars | Mafia Pro Jump 1 W762mm X H62mm |
| Grips | Mafiabikes Lucky 6 150mm |
| Headset | 1 1/8” -1.5″ Tapered – Integrated – Sealed bearings |
| Stem | Forged Frontload – Ø31.8 |
| Pedals | 9/16” Mafiabikes plastic |
| Saddle | Mafiabikes 1 Piece mid integrated alloy post – Ø25.4 |
| SEATPOST | Ø25.4mm integrated with seat |
| Seat Clamp | Ø35mm External |
| Cranks | 170mm 4130 chromoly heat treated 19mm 8 spline 3 piece cranks |
| Chainring/sprocket front | 25t Mafiabikes Steel Sprocket |
| Sprocket/cassette rear | 10t Fully sealed Cassette |
| Tyre Front | Kenda Small Block Eight 26″ x 2.35″ |
| Tyre Rear | Kenda Small Block Eight 26″ x 2.1″ |
| Front hub | 20mm x 110mm, sealed bearings, Disc |
| Rear hub | Alloy shell, 3/8″ axle, Fully sealed bearings, Disc |
| Rim rear | 26″ Double wall alloy 32h |
| Rim front | 26″ Double wall alloy 32h |
| Brake Front | Mechanical disc brake 160mm rotor (supplied in roadkit) |
| Brake Rear | Zoom – hydraulic disc brake 160mm rotor |
| Tyres | Lagos Snakeskin 2 26″x2.5″ (Front)/ Kenda kiniption 26″x2.3″ (Rear) |
| Tech | |
| Weight (lbs) | 30.200000 |
| Frame weight | 2.0Kg |
| BB type | 73mm ISO Euro (19mm) |
| Headset type | 1 1/8” -1.5″ tapered integrated |
| Rear axle/hub spacing | 3/8″ x 135mm axle |
| Max tyre width rear | 66mm / 2.6″ |
| Seatpost/seatclamp | Ø25.4mm post with Ø31.8 shim, Ø35 seatclamp |
| Front axle/hub spacing | 20 x 110 Thru axle |
| Frame construction and details | 6061 T6 Alloy .Forged dropouts .Integrated chain tensioners .CNC headtube .IS Disk mount .Bespoke Hydroformed tubes .ISO Threaded BB |
| Road kit | Included |
| Fork construction | Straight steerer |
